Electrical Hazards
Insulation integrity, protective earth connections, leakage current limits, shock protection
Medical device manufacturers face complex compliance requirements across electrical safety, electromagnetic compatibility, and wireless certification. MiCOM Labs delivers A2LA-accredited testing services under ISO/IEC 17025 that help connected medical devices, diagnostic equipment, and laboratory instruments meet global regulatory requirements.
Electromagnetic compatibility testing ensures medical devices operate reliably in clinical environments without causing or experiencing interference.
| Test Type | Application | Standard |
|---|---|---|
| Radiated Emissions | Prevents interference with nearby medical equipment | IEC 60601-1-2, EN 55032, FCC Part 15 |
| Conducted Emissions | Eliminates power line interference in healthcare facilities | IEC 60601-1-2, EN 55032, ICES-003 |
| Harmonic Current Emissions | Protects power grid stability in hospitals | IEC 61000-3-2, IEC 60601-1-2 |
| Voltage Fluctuations and Flicker | Maintains power quality for life-supporting equipment | IEC 61000-3-3, IEC 60601-1-2 |
Prevents interference with nearby medical equipment
IEC 60601-1-2EN 55032, FCC Part 15Eliminates power line interference in healthcare facilities
IEC 60601-1-2, EN 55032, ICES-003Protects power grid stability in hospitals
IEC 61000-3-2, IEC 60601-1-2Maintains power quality for life-supporting equipment
IEC 61000-3-3, IEC 60601-1-2| Test Type | Application | Standard |
|---|---|---|
| Radiated Immunity | Ensures device function during RF exposure from wireless equipment | IEC 61000-4-3, IEC 60601-1-2, EN 55035 |
| Conducted Immunity | Validates operation during power line disturbances | IEC 61000-4-6 |
| ESD Immunity | Prevents system failure from static discharge in clinical settings | IEC 61000-4-2 |
| Surge Immunity | Protects against transient-induced failures | IEC 61000-4-5 |
| Electrical Fast Transients | Maintains function during switching events | IEC 61000-4-4 |
| Voltage Dips and Interruptions | Ensures operation during power supply variations | IEC 61000-4-11, IEC 61000-4-29 |
Ensures device function during RF exposure from wireless equipment
IEC 61000-4-3, IEC 60601-1-2, EN 55035Validates operation during power line disturbances
IEC 61000-4-6Prevents system failure from static discharge in clinical settings
IEC 61000-4-2Protects against transient-induced failures
IEC 61000-4-5Maintains function during switching events
IEC 61000-4-4Ensures operation during power supply variations
IEC 61000-4-11, IEC 61000-4-29Medical devices require electrical safety verification in accordance with IEC 60601-1 to protect patients and operators across all hazard categories.
Testing coverage ensures medical devices are evaluated across all major safety risk categories.
Insulation integrity, protective earth connections, leakage current limits, shock protection
Equipment stability, moving parts, sharp edges, resistance to mechanical stress
Temperature-rise testing, acessible surface limits, heat-related ignition prevention
Material evaluation, Insulation systems, Fire propagation control
Optical radiation limits, acoustic pressure levels, ionizing radiation sources
Liquid exposure protection, contamination prevention, cleaning fluid resistance
Connected medical devices require regulatory approval across multiple markets. MiCOM Labs provides RF testing and certification for wireless medical technologies.
Frequency range up to 220 GHz
FCC Part 15, Part 18, Part 27 compliance
ISED RSS compliance for Canadian market access
EU RED radio equipment testing
UKCA compliance for the UK market
MIC Japan type approval
Antenna performance evaluation
Medical device manufacturers choose MiCOM Labs for its accredited testing, integrated compliance platforms, and direct certification capabilities across global markets.
MiCOM Labs maintains A2LA accreditation (Certificate #2381.01) for testing laboratory operations. Test results meet the documentation and traceability standards required for regulatory submissions to the FDA, Health Canada, and European regulatory bodies.
The MiTest® platform automates test execution and provides live project status updates. Medical device manufacturers can monitor testing progress in real time and access provisional results before final reports are complete. This automation reduces test time while ensuring comprehensive coverage of all applicable requirements.
The MiCMS® platform provides end-to-end workflow management for certification applications. Medical device teams can track certification status, manage documentation, and receive automated alerts throughout the compliance process. The system maintains ISO/IEC 17065 compliance for certification body operations.
| Market | Regulatory Authority | MiCOM Labs Role |
|---|---|---|
|
🇺🇸
United States
|
FCC | Telecommunication Certification Body (TCB) |
|
🇨🇦
Canada
|
ISED | Foreign Certification Body (FCB) |
|
🇪🇺
European Union
|
CE | Notified Body under US-EU MRA |
|
🇬🇧
United Kingdom
|
UKCA | Approved Body under US-UK MRA |
|
🇯🇵
Japan
|
MIC | Registered Certification Body (RCB) |
The medical device compliance process follows a structured sequence to ensure accurate testing and timely certification.
Equipment specifications reviewed, user manuals evaluated, applicable standards identified
Detailed test protocol developed, sample requirements documented, timeline estimated
Electrical safety verification, EMC evaluation, RF compliance testing, environmental validation
ISO/IEC 17025-compliant test reports issued, compliance determinations documented
Applications submitted to regulatory authorities, status tracking via MiCMS®, and declarations of conformity issued
Equipment specifications reviewed, user manuals evaluated, applicable standards identified
Detailed test protocol developed, sample requirements documented, timeline estimated
Electrical safety verification, EMC evaluation, RF compliance testing, environmental validation
ISO/IEC 17025-compliant test reports issued, compliance determinations documented
Applications submitted to regulatory authorities, status tracking via MiCMS®, and declarations of conformity issued
MiCOM Labs supports a wide range of industries requiring rigorous medical device testing and compliance.
In vitro diagnostic systems, clinical chemistry analyzers, and hematology instruments require comprehensive testing before regulatory approval.
Wireless patient monitors, remote diagnostic equipment, and telehealth systems need RF compliance certification. Testing covers wireless performance, electromagnetic compatibility, and electrical safety requirements.
Medical imaging accessories, laboratory test equipment, and diagnostic analyzers require testing that validates both safety compliance and electromagnetic compatibility in healthcare environments.
Universities, government laboratories, and private research facilities use specialized measurement equipment that requires certification before institutional approval and regulatory acceptance.
MiCOM Labs provides comprehensive testing services under one A2LA-accredited facility:
A2LA-accredited electromagnetic compatibility and interference evaluation
Up to 220 GHz frequency range
2D/3D radiation patterns, gain measurement, efficiency analysis
Temperature cycling, humidity exposure, vibration testing
EU RED Article 3.3 compliance for connected devices
Dynamic Frequency Selection for spectrum-sharing devices
Citizens Broadband Radio Service compliance
Medical device manufacturers targeting international markets face varying regulatory requirements. MiCOM Labs coordinates testing and certification across multiple jurisdictions to streamline global market entry.
For countries requiring mandatory in-country testing, MiCOM Labs coordinates with accredited local laboratories to manage project execution and regulatory submissions.
MiCOM Labs delivers A2LA-accredited testing services for medical device manufacturers navigating global compliance requirements. Our automated testing platforms and direct certification authority in major markets reduce time-to-market while ensuring regulatory acceptance.
Contact MiCOM Labs to discuss your device specifications, target markets, and testing requirements. Receive a detailed proposal outlining applicable standards, testing scope, and certification timelines.
